Screw oil press

Automatic Screw Oil Press has a high degree of automation, adopts high pressure vacuum filtering system and automatic temperature control heating press technology. It is widely used to process rapeseed, cottonseed, sesame, sunflower, grainy oil plant seeds as well as corn germ, etc. into high quality edible oil. Automatic Screw Oil Press can not only press oil but also filter oil by vacuum filtering device that is why Automatic screw oil press can be used widely in small and large scale oil pressing plants

Oil Press Introduction

Screw oil press is also appropriate for many oil bearing materials such as: flax seed,peanut, soybean, sunflower,corn,coconut, palm kernel,baobab seed,mustard seed,shea seed, etc.
Furthermore, it can be used for both cold pressing and hot pressing. Capacity ranges from 1t/d to 24t/d make that  automatic screw  oil press is suitable both for family use and large plant.




Send Email   Get Price


Application of Oil Press

Screw oil press is appropriate for many oil bearing materials such as: flax seed,peanut, soybean, sunflower,corn,coconut, palm kernel,baobab seed,mustard seed,shea seed, etc.

Furthermore, it can be used for both cold pressing and hot pressing. Capacity ranges from 1t/d to 24t/d make that  automatic screw  oil press is suitable both for family use and large plant.



Our Certificate



Oil Press Features

1. Screw Oil Press also can press more than 15 kinds of oil plant seeds, such as flax seed,peanut, soybean, sunflower,corn,coconut, palm kernel,baobab seed,mustard seed,shea seed, etc.

2. High oil yield and  High purity edible oil .

3. The wear parts such as the pressing rings, worms are made of the carbon steel which is under the process of heat pretreatment, making them very durable.

4. Screw oil press is Safety and convenience. The whole process is controlled by electric cabinet, so that it is  more safety and easy to operate.

5 Screw oil press saves 60% labor for equal output, and one or two people can  operate independently.


Technical Data

Model

Capacity

kg/h

Speed

r/min

Voltage Power Weight Overall Size (mm)
BYL-68 40-70 30-40 380V 5.5kw 150KG 920x390x750
BYL-98 100-150 30-40 380V 7.5kw 370KG 1920x550x765
BYL-100 150-200 30-40 380V 7.5kw 550KG 1920x550x765
BYL-120 250-300 30-35 380V 15kw 680KG 2100x610x785
BYL-130 400-500 28-33 380V 18.5kw 800KG 2300x760x860
860x500x560
BYL-140 500-600 28-33 380V 22kw 960KG 2460x800x870
900x560x600
BYL-160 650-700 22-28 380V 30kw 1600KG 2290x750x1020
880x750x760
BYL-165 800-850 30-40 380V 37kw 1800KG 2400x780x1100
900x850x880
BYL-200 900-1000 30-40 380V 37kw 2500KG 2600x1000x1450
900x850x880
